Product Description
Unleash the sound of music to it full potential with the MM1002 a MINI Two-Channel Amplifier
Designed with band-passable crossovers X1 & X10, this dynamic amplifier allows you to run mids and highs on one channel and bass on the other, or bi-amplify the 2 channels differently for a customizable listening experience.
**Technical Specifications:**
- 4ohm rms power : 100W x 2ch
- 2ohm rms power : 160W x 2ch
- 4ohm rms bridged power : 350W x 1ch
- Tested at 14,4V & 1% THD.
- Frequency response : 10Hz –23.97KHz
- Signal to noise : 91dB
- Damping factor : 100
- Input sensitivity : 6V –0.2V
- High Pass Filter : 20Hz –800Hz
- HighPass multiply : x1, x10 ( 200Hz –8Khz )
- Low Pass Filter : 50Hz –800Hz
- Low PassMultiply : x1, x10 ( 500Hz –8Khz )
- Bandpass capable
- Clipping Indicator
- Working voltage : 9 to 15.5Volts.
- Dimensions : 170mm L x 123.9mm W x 54.3mm H
- (6.69 x 4.87 x 2.13 inches )
- 4 GA Power & Ground Terminal
- 14GA Speaker wire Terminal
