CS68


FS:40hz

QTS:. 39

QES: .42

QMS: 4.468

VAS: 5.744

BL: 20

MMS: 172G

CMS: .09

SENS: 81 1W1M

Displacement .10

Ported .5-.75 @32 16 sqin of port

Xmax 19mm

Cut out  7.43

Mounting depth "6.75


CS610


FS: 36

QTS: 43

QES: 48

QMS: 4.515

VAS: 12.94 L

BL: 23

MMS: 274G

​CMS: .07 MM/N

​SENS: 83 1W/1M
Displacement .10FT^3
Sealed .6 FT^3

Ported 1.0-1.25 FT^3 @ 34 HZ 14 sqin of port

Cut out 9.30"

Mounting depth "7.75

Xmax 19mm

CS612


FS: 37

QTS: .5

QES: .62

QMS: 4.78

VAS: 25.53 L

BL: 22

MMs: 297G

CMS: .06 MM/N

SENS: 85 1W/1M

Displacement .15FT^3

sealed 1.15 FT^3

ported 1.5-2.0 FT^3 @ 34hz 15sqin of port

Cut out 11.25"

Mounting depth "7.5

Xmax 25mm

CS615


FS: 30

QTS: .5

QES.59

QMS: 4.9

VAS: 108.9L

BL: 21

MMS: 307G

CMS: .09 MM/N

SENS: 88 1W/1M

Displacement .17FT^3

Sealed 2.5 FT^3

Ported 3.0-4.0 FT^3 @ 34​

Cut out 14.125"

Mounting depth "9.25

Xmax 25mm
